File:826 encoder FLT.png
From Sensoray Technical Wiki
No higher resolution available.
Using an 826 counter channel to monitor an incremental encoder's active-low FAULT output. The differential pair is swapped between line driver and receiver so that a disconnected or unpowered encoder will be recognized as a fault.
